Klein® IR5
  • https://www.mallory.com//ASSETS/DOCUMENTS/ITEMS/EN/KLEIN-IR5.pdf
  • https://www.mallory.com//ASSETS/DOCUMENTS/ITEMS/EN/KLEIN-IR5_1.pdf

Klein® IR5 Infrared Thermometer, -22 to 752 deg F, +/- 2%, 12:1

  • ITEM CODE: KLEIN-IR5
  • UPC: 092644690303

  • Min. Order Qty: 1
  • Qty. Interval: 1

loading

Klein® IR5

DESCRIPTION

Klein Tools IR5 is a professional dual-laser targeting infrared thermometer, offering a wide measurement range, a tight 12:1 distance-to-spot ratio, dual targeting lasers and several calculation modes to facilitate different temperature measurement applications. The dual lasers assist in targeting the measurement area. The distance between the two laser spots on the surface of the object being measured approximates the diameter of the circular measurement area from which the infrared sensor is collecting data.


Infrared Thermometer, Dual Laser, -22 to 752 deg F, +/- 2% Accuracy, Resolution: 12:1, Adjustable Emissivity, (1) 9 V Battery, Digital Backlit LCD, <0.25 Sec Response, Dimensions: 6.82 in L x 1.84 in W x 4.53 in H

APPLICATIONS

Accurate Targeting and Temperature Measurement

SPECIFICATIONS

FEATURES

  • Optical Resolution (Distance-to-spot) is 12:1
  • Features include dual-laser targeting; auto-scan; max/min/avg/diff, high/low alarm; backlit display, auto power-off
  • Drop protection to 6.6 ft (2 m)
  • Not a medical device; thermometer is NOT intended for use on people or animals
  • Uses one 9-volt battery, with battery life expectancy at 10 hours of continuous use with laser and backlight on
  • Includes custom pouch and batteries
  • Adjustable emissivity
  • Soft-touch, over-mold housing
  • For ambient temperatures above freezing, the accuracy is +/- 4 deg F or +/- 2-percent; Accuracy below freezing is +/- 4-deg F plus 0.2 deg per deg below 32-deg F
  • Certified to IEC EN 61326-1.2006, EN608251.1994+A2.2001+A1.2002

REFERENCES

  • pdf FILE https://www.mallory.com//ASSETS/DOCUMENTS/ITEMS/EN/KLEIN-IR5.pdf
  • pdf FILE https://www.mallory.com//ASSETS/DOCUMENTS/ITEMS/EN/KLEIN-IR5_1.pdf
