Harrington Hoists HARRINGTON SNER030C Electric Chain Hoists, 6000 lb Capacity, 10 ft Lifting Height, 3.5 fpm Lift Speed
- Manufacturers: Harrington Hoists
- Brand Name: HARRINGTON
- ITEM CODE: HARRI-SNER1-867136
- Mfr Part: SNER030C
- Min. Order Qty: 1
- Qty. Interval: 1
- Sold As:
-
Price:
HARRINGTON SNER030C
DESCRIPTION
Electric Chain Hoists, 6000 lb Capacity, 10 ft Lifting Height, 3.5 fpm Lift Speed, 29-1/2 in Minimum Between Hooks, 110V Push Button Control Pendant Control, Pull Rotor Motor Brake, 1 Ph 60 Hz, 115 V, 23.9 A, Yellow, 13-3/16 in Wd, 29-1/2 in Lg, 8-5/16 in Dp
| Amperage Rating | : | 23.9 A |
| Brake Type | : | Pull Rotor Motor |
| Color | : | Yellow |
| Control Type | : | 110V Push Button Control Pendant |
| Dimensions | : | 13-3/16 in Wd, 29-1/2 in Lg, 8-5/16 in Dp |
| Lift Speed | : | 3.5 fpm |
| Minimum Between Hooks | : | 29-1/2 in |
| Load Capacity | : | 6000 lb |
| Lifting Height | : | 10 ft |
| Power Rating | : | 1 Ph 60 Hz |
| Voltage Rating | : | 115 V |
- Extreme Duty Motor Higher horsepower and top duty ratings provide increased performance.<\li>
- Pull-Rotor Motor Brake Extremely durable and reliable, this advanced design has no brake coil to fail.<\li>
- Unique Chain Guide Provides quiet and smooth guiding of chain. Easily removed without disassembly of hoist. Heavy cast iron construction for improved wear<\li>
- Load Sheave Deep-groove pockets fully support the load chain, reduces vibration and chain wear and provides a true vertical lift.<\li>
- Long Life Friction Clutch Protects hoist from damage and prevents overwinding.<\li>
- Heat Treated Helical and Spur Gears Precision machined for long life. Oil bath lubrication results in a quiet, smooth, cool operation.<\li>
- Completely Sealed Body Suitable for indoor, outdoor and harsh environments.<\li>
- Compact Aluminum Body Die-cast body is lightweight and offers low headroom.<\li>
- Easy Maintenance Control Panel Fast on-site access with hinged cover, single swing-out panel and simple layout of controls.<\li>
- Superior Quality Chain Grade 80 nickel-plated load chain is heat treated for wear resistance and extended life.<\li>
- Forged Carbon Steel Hooks Under excessive loads will open gradually and not fracture. Bottom hook swivels 360 degrees<\li>
- Motorized Trolley Side Guide Rollers Provide smooth trolley motion and reduced wear on wheels and beam<\li>
- Motorized Trolley Drop Stops and Rubber Bumpers Built-in security for the operator and added protection for the equipment and load.<\li><\ul>
- ASME B30.16, ASME HST-1, NFPA 70
