Seco 02551636 MDT Double End Turning Insert, ANSI Code: LCMF1606M0-0600-MP CP200, LCMF Insert, Material Grade: M, S, 1606 Insert, Rectangle Shape, 16 Seat, Neutral Cutting, For Use On Stainless Steel, Super Alloys and Titanium, Carbide
- Manufacturers: Seco Tools
- Brand Name: Seco
- ITEM CODE: SECOT-30159
- Mfr Part: 02551636
- Min. Order Qty: 1
- Qty. Interval: 1
- Sold As: 10/PK
-
Price:
Seco 02551636
DESCRIPTION
Seco Turning Insert, Double End, Series: MDT, LCMF Insert, 1606 Insert, Rectangle Shape, 4.12 mm Thickness, 6 mm Width, 17.9 mm Length, 16 Seat, MP Chipbreaker, 3 mm Corner Radius, Manufacturer's Grade: CP200, ANSI Code: LCMF1606M0-0600-MP CP200, ISO Code: LCMF1606M0-0600-MP CP200, 7 deg Relief Angle, Neutral Cutting Direction, Carbide, PVD-TiAlN+TiN Coated, Material Grade: M, S, For Use On: Stainless Steel, Super Alloys and Titanium
APPLICATIONS
For medium profiling, turning and good accessibility
| ANSI Code | : | LCMF1606M0-0600-MP CP200 |
| Chipbreaker | : | MP |
| Corner Radius | : | 3 mm |
| Finish | : | PVD-TiAlN+TiN Coated |
| ISO Code | : | LCMF1606M0-0600-MP CP200 |
| Length | : | 17.9 mm |
| Relief Angle | : | 7 deg |
| Series | : | MDT |
| Thickness | : | 4.12 mm |
| Type | : | Double End |
| Width | : | 6 mm |
| Insert Style | : | LCMF |
| Material Grade | : | M, S |
| Insert Size | : | 1606 |
| Shape | : | Rectangle |
| Seat Size | : | 16 |
| Cutting Direction | : | Neutral |
| For Use On | : | Stainless Steel, Super Alloys and Titanium |
| Material | : | Carbide |
