Proto® TorquePlus™ ProtoBlack™ J1222MBASD Anti-Slip Design Combination Wrench, Metric, 22 mm, 12 Points, 15 deg Offset, 318.1 mm OAL, Alloy Steel, Black Oxide, ASME B107.100
- Manufacturers: Stanley Black & Decker
- Brand Name: Proto®
- ITEM CODE: STAPR-J1222MBASD
- Mfr Part: J1222MBASD
- UPC: 662679073831
- Min. Order Qty: 1
- Qty. Interval: 1
- Sold As:
-
Price:
Proto® J1222MBASD
DESCRIPTION
Proto® TorquePlus™ ProtoBlack™ Combination Wrench, Anti-Slip Design, Measurement System: Metric, Spline Wrench, 22 mm Wrench Opening, 12 Points, 318.1 mm Overall Length, 15 deg Offset, 45.5 mm Open End Width, 10.3 mm Open End Thickness, 32.5 mm Box End Width, 13.9 mm Box End Thickness, 15 deg Head, ASME B107.100 Specifications Met, 26.5 mm Throat Depth, Straight Handle, Alloy Steel, Black Oxide
| Box End Thickness | : | 13.9 mm |
| Box End Width | : | 32.5 mm |
| Handle Type | : | Straight |
| Head Angle | : | 15 deg |
| Open End Thickness | : | 10.3 mm |
| Open End Width | : | 45.5 mm |
| Throat Depth | : | 26.5 mm |
| Type | : | Anti-Slip Design |
| Wrench Type | : | Spline |
| Measurement System | : | Metric |
| Wrench Opening | : | 22 mm |
| Number of Points | : | 12 |
| Offset Angle | : | 15 deg |
| Overall Length | : | 318.1 mm |
| Material | : | Alloy Steel |
| Finish/Coating | : | Black Oxide |
| Specifications Met | : | ASME B107.100 |
- Non-reflective black oxide finish for use where non-plated products are required
- 12 point box end allows for fine indexing, helping to improve speed and access
- Fits 4, 6 and 12 point fasteners
- The box end is countersunk for easy application to the fastener
- 15 deg angled offset box end helps keep shank clear of obstructions
- Anti-slip design (ASD) open end
- Box ends incorporate the TorquePlus™ system
- ASME B107.100
