Proto® TorquePlus™ J7722HT Deep Length Thin Wall Socket, Imperial, 3/8 in Square Drive, 11/16 in
- Manufacturers: Stanley Black & Decker
- Brand Name: Proto®
- ITEM CODE: STAPR-J7722HT
- Mfr Part: J7722HT
- UPC: 662679331764
- Min. Order Qty: 1
- Qty. Interval: 1
- Sold As:
-
Price:
Proto® J7722HT
DESCRIPTION
Proto® TorquePlus™ Socket, Deep Length Thin Wall, Yes Impact Rated, Measurement System: Imperial, Square Drive, 3/8 in Drive, 11/16 in Socket, 2-3/4 in Overall Length, 1/2 in Opening Depth, 15/16 in Drive End Width, 15/16 in Socket End Width, 6 Points, 1-11/16 in Bolt Clearance Depth, Alloy Steel, Black Oxide
APPLICATIONS
For use on stubborn or damaged fasteners and also on fasteners made from soft materials, light clearance applications
| Bolt Clearance Depth | : | 1-11/16 in |
| Drive End Width | : | 15/16 in |
| Finish | : | Black Oxide |
| Material | : | Alloy Steel |
| Opening Depth | : | 1/2 in |
| Overall Length | : | 2-3/4 in |
| Socket End Width | : | 15/16 in |
| Type | : | Deep Length Thin Wall |
| Impact Rated | : | Yes |
| Measurement System | : | Imperial |
| Drive Type | : | Square |
| Drive Size | : | 3/8 in |
| Socket Size | : | 11/16 in |
| Number of Points | : | 6 |
- Reduced wall thickness helps improve access to fasteners in restricted areas
- All impact sockets feature one through hole and a groove to accept a retaining ring and pin to secure the socket to the power tool anvil
- Chamfered service ends for quick and positive fastener engagement
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners
- The TorquePlus™ configuration employs a radius corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life and allows the user to more easily turn worn, rounded or rusted fasteners
- Thin wall sockets are lightweight
- Designed to fit into smaller spaces
- Thinner walls help improve productivity by making it easier to gain access to fasteners in confined spaces
- Extra deep length helps improve access in confined areas
- Often used in application where fasteners are close together, such as tire service
- ASME B107.110-2012
