Proto® J1174
  • https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_17d3881ce18086650babc073402e5181ce7aa18f8980033ae889c8852fb2d6ce.pdf

Proto® TorquePlus™ J1174 Box End Wrench, 13/16 x 7/8 in Wrench, 12 Points, 15 deg Offset, 13-1/8 in OAL, Alloy Steel, Full Polished, ASME B107.100, AS954E S3.8.1, ANSI B107.6, Federal GGG-W-636E

  • ITEM CODE: STAPR-J1174
  • UPC: 662679061647

  • Min. Order Qty: 1
  • Qty. Interval: 1

loading

Proto® J1174

DESCRIPTION


Proto® TorquePlus™ Box End Wrench, Measurement System: Imperial, Double End/Spline Wrench, 13/16 x 7/8 in Wrench Opening, 12 Points, 13-1/8 in Overall Length, 15 deg Offset, 1-19/64 x 1-3/16 in Box End Width, 33/64 x 31/64 in Box End Thickness, Oval Handle, Specifications Met: ASME B107.100, AS954E S3.8.1, ANSI B107.6, Federal GGG-W-636E, Alloy Steel, Full Polished

APPLICATIONS

For stubborn or damaged fasteners

SPECIFICATIONS

FEATURES

  • Full polish finish provides corrosion resistance and easy-to-clean surfaces
  • 12 point box end allow for fine indexing, helping to improve speed and access
  • Fits 4, 6 and 12 point fasteners
  • Box ends incorporate the TorquePlus™ system
  • Radius corner socket design
  • Engages flats for better grip
  • Improves the ability to turn worn or rounded fasteners
  • Standard 15 deg offset for knuckle clearance
  • Allows upto 15% more torque to be applied to the fastener
  • Reduces the risk of fastener rounding
  • Provides a better grip on worn, rounded fasteners
  • Double nickel strike for rust resistance and prolonged life
