Chicago-Latrobe® 50580 120X Heavy Duty Extra Length Drill, 33/64 in Drill - Fraction, 0.5156 in Drill - Decimal Inch, 10 in OAL, HSS
- Manufacturers: Greenfield Industries
- Brand Name: Chicago-Latrobe®
- ITEM CODE: GREIN-50580
- Mfr Part: 50580
- UPC: 662355505809
- Min. Order Qty: 1
- Qty. Interval: 1
- Sold As: 1/PK
-
Price:
Chicago-Latrobe® 50580
DESCRIPTION
Chicago-Latrobe® Extra Length Drill, Heavy Duty, Series: 120X, 33/64 in Drill - Fraction, 0.5156 in Drill - Decimal Inch, 10 in Overall Length, 7-1/2 in Cutting Depth, 2 Flutes, Spiral Flute, 7-1/2 in Flute Length, 33/64 in Shank, Straight Shank, 118 deg Point, K-Notch Point, Right Hand Cutting Direction, HSS Cutting Edge, HSS, Black Oxide/Steam Oxide, Applicable Materials: Alloy Steel, Carbon Steel and Cast Iron, No Through Coolant
APPLICATIONS
For long reach applications
| Cutting Depth | : | 7-1/2 in |
| Cutting Direction | : | Right Hand |
| Cutting Edge Material | : | HSS |
| Finish | : | Black Oxide/Steam Oxide |
| Flute Length | : | 7-1/2 in |
| Flute Type | : | Spiral |
| Number of Flutes | : | 2 |
| Point Angle | : | 118 deg |
| Point Type | : | K-Notch |
| Series | : | 120X |
| Shank Size | : | 33/64 in |
| Shank Type | : | Straight |
| Type | : | Heavy Duty |
| Drill Size - Fraction | : | 33/64 in |
| Drill Size - Decimal Inch | : | 0.5156 in |
| Overall Length | : | 10 in |
| Material | : | HSS |
| Applicable Materials | : | Alloy Steel, Carbon Steel and Cast Iron |
| Through Coolant (Yes/No) | : | No |
- Heavy duty construction and extra length to drill in a wide range of applications where extra reach is needed
- Black oxide finish provides increased wear resistance and added lubricity in ferrous material
